Fiamma Astrolab 3 Group Coffee Machine

Sale price
$14,380.00
Regular price
$15,818.00
You save
$1,438.00 (10%)
Tax included. Shipping calculated at checkout.

Frequently Bought Together
Di Pacci — 3 Group Multi-Boiler PID Commercial Espresso Machine

Fiamma Astrolab 3 Group Coffee Machine

The Fiamma Astrolab 3 Group gives each group its own PID-controlled coffee boiler, for multi-boiler consistency at a busy-cafe scale.

The Fiamma Astrolab 3 Group is a multi-boiler commercial espresso machine: three independent 0.5 L coffee boilers with PID temperature control, a 12 L steam and water boiler and a rotary pump. Shot timers, dose counters, pre-infusion, programmable hot water portions and automatic cleaning are all built in.

It's designed to keep running costs and downtime down as well as cups consistent. Incoming water is pre-heated, sequential heating staggers the elements at start-up, and there's an energy-saving mode. Smart alerts flag when it needs attention, and the two cool-touch steam wands and two hot water taps keep the milk side moving.

3 × 0.5 LPID coffee boilers
12 LSteam boiler
RotaryPump
400 VMulti-phase supply
🔥 Multi-Boiler 🌡️ PID per Group ⏱️ Shot Timers 🔔 Smart Alerts 💧 Pre-Infusion 🧽 Auto Cleaning 💡 LED Lighting ✅ In Stock — Australia
Best for: ☕ High-volume cafes · 🫘 Speciality espresso bars · 🏨 Hotels · 🍽️ Restaurants · 🏪 Multi-barista venues
Free standard shipping Australia-wide on orders over $200. Standard shipping is $14.95 for orders below $200. Same-day dispatch for orders placed before 2PM, with secured, tracked delivery. Free commercial machine installation for Sydney metro areas.
All Commercial Coffee Machines Finance Options Talk to an Expert — (02) 9758 0760

Key Features of the Fiamma Astrolab

🔥 Independent coffee boilers

Each group has its own 0.5 L coffee boiler, so a rush on one group doesn't drag the others off temperature.

🌡️ PID temperature control

Digital control holds the brew temperature you set on each group.

⏱️ Shot timers and counters

Built-in timers and dose counters help staff keep extractions consistent and track volume.

🔔 Smart alerts

The machine flags service and cleaning needs before they turn into a breakdown.

🥛 Two cool-touch steam wands

Cool-touch wands and two hot water taps keep two people working the milk and water side.

♻️ Energy saving

Pre-heated incoming water, sequential heating and an energy-saving mode trim power use.

Multi-Boiler vs Heat Exchanger on a 3 Group

Most 3 group machines heat brew water through heat exchangers in one big steam boiler. The Astrolab gives each group its own small coffee boiler instead.

  • The 12 L boiler is left to do steam and hot water only.
  • Each 0.5 L coffee boiler is held at its own set temperature by PID.
  • Temperature on one group isn't affected by heavy steaming or by the groups beside it.

On a three-barista bar, that means the third shot in a rush tastes like the first, and you can run different coffees on different groups.

Complete Technical Specifications

Product Information
Brand Fiamma
Model Astrolab
Groups 3
Warranty 12 months parts & labour via Di Pacci
Boilers & Groups
Boiler technology Multi-boiler
Coffee boilers 3 × 0.5 L, 3 × 1.5 kW
Steam / water boiler 12 L, 3.5 kW
Temperature control PID
Pre-infusion Yes
Preheated water Yes
Control
Shot timer Yes
Dose counters Yes
Smart alerts Yes
Automatic cleaning Yes
Energy saving Energy-saving mode and sequential heating
Pump, Steam & Water
Pump Rotary
Steam wands 2, cool touch, with steam knobs
Hot water taps 2, temperature controlled, programmable portions
Physical & Power
Dimensions (W × D × H) 1050 × 630 × 510 mm
Weight 88 kg
Power 5.25–8.75 kW
Voltage 400 V 2N~
Finish Stainless steel, LED lighting, cup warmer
Installation Plumbed water, drain and dedicated multi-phase supply required

Ask us to confirm the electrical configuration for your site before ordering; the standard supply is 400 V two-phase plus neutral.

What's in the Box

  • Fiamma Astrolab 3 group espresso machine
  • Portafilters and filter baskets (ask us to confirm the exact kit)

You'll also need a commercial grinder, a water filter, and a licensed plumber and electrician for installation.

Fiamma Astrolab vs Synesso Cyncra 3 Group

Both are 3 group multi-boiler machines with per-group temperature control. They differ in boiler sizes and power supply.

Feature Fiamma Astrolab 3gr Synesso Cyncra 3gr
Coffee boilers 3 × 0.5 L 3 × 1.9 L
Steam boiler 12 L 12.3 L
Power supply 400 V 2N~ 240 V 40 A single phase or three phase
Width 1050 mm 1042 mm
Weight 88 kg 86 kg

Di Pacci recommendation: The Astrolab gives you multi-boiler stability with shot timers and smart alerts built in. Choose the Synesso Cyncra if you want larger brew boilers or a single-phase option. Don't bother with a 3 group at all if you rarely have three people on the bar; a 2 group saves bench space and power.

Best Grinders for the Fiamma Astrolab

Three groups need on-demand grinding that can keep up, ideally one grinder per coffee you serve.

Grinder Burrs Why it pairs well
Mahlkönig E65S 65 mm flat Fast on-demand dosing that keeps up with a 2 group bar
Fiorenzato F83 E Pro 83 mm flat Large burrs grind cool and quick for high-volume milk trade
Mazzer Kony S Electronic Conical Conical burrs give a fuller-bodied shot that carries through milk

Browse the complete commercial grinder range for more options.

Who This Machine Is For

✓ Ideal if you:
  • Run a high-volume cafe with three baristas
  • Want each group at its own stable temperature
  • Like built-in shot timers and dose counters
  • Have a multi-phase 400 V supply
  • Have at least 105 cm of bench
✗ Consider alternatives if you:
  • Only have single-phase power; see the Synesso Cyncra
  • Rarely have three people on the bar
  • Have less than 105 cm of bench
  • Want a home machine; see our home coffee machines

Fiamma Astrolab 3 Group — Frequently Asked Questions

Is the Fiamma Astrolab a multi-boiler machine?

Yes. It has three independent 0.5 litre coffee boilers, one per group, with PID temperature control, plus a 12 litre steam and hot water boiler.

What power does the Fiamma Astrolab 3 Group need?

It's rated at 5.25 to 8.75 kW on a 400 V two-phase plus neutral supply. A licensed electrician must install a dedicated supply.

How big is the Fiamma Astrolab 3 Group?

It measures 1050 mm wide, 630 mm deep and 510 mm high, and weighs 88 kg.

Does the Astrolab have shot timers?

Yes. Shot timers and dose counters are built in, along with smart alerts for service and cleaning.

Does the Fiamma Astrolab need plumbing?

Yes. It needs a mains water connection with filtration and a drain.

Do you install the Fiamma Astrolab?

Yes. Installation is free in Sydney metro areas and our technicians service the machine. Call (02) 9758 0760 to plan your fit-out.

Why Buy the Fiamma Astrolab from Di Pacci

Genuine Australian stock of Fiamma equipment, an in-house service team with parts in stock, five showrooms (Sydney/Roselands, Melbourne, Perth, Port Macquarie, Queensland), in-store demonstrations, expert pairing advice, finance options, free shipping over $200, and a 12 month parts & labour warranty through Di Pacci. Free commercial machine installation is available for Sydney metro areas. Di Pacci Coffee Co. has been in coffee since 2003.
